Gigabyte Radeon RX 9070 GAMING OC 16GB Graphics Card

The Gigabyte Radeon RX 9070 GAMING OC 16G delivers high-performance gaming with 16GB GDDR6 memory across a 256-bit interface. Built on AMD's latest architecture, this graphics card features 3584 stream processors across 56 compute units, providing the processing power needed for demanding games and applications at high resolutions up to 7680 x 4320.

Advanced WINDFORCE Cooling System

The WINDFORCE cooling solution employs triple Hawk fans designed for efficient heat dissipation during extended gaming sessions. Server-grade thermal conductive gel ensures optimal thermal transfer between the GPU and heatsink, maintaining stable performance under load. The dual BIOS feature allows switching between Performance and Silent modes, letting you prioritize either maximum output or quieter operation based on your needs.

PCIe 5.0 and Modern Connectivity

This graphics card supports PCI Express 5.0, ensuring compatibility with the latest motherboards and future-proofing your system. The card provides comprehensive display connectivity with three DisplayPort 2.1a outputs and one HDMI 2.1b port, supporting multi-monitor setups with up to four displays simultaneously. DirectX 12 API and OpenGL 4.6 support ensure compatibility with current and upcoming game titles.

RGB Lighting and Reinforced Design

Customizable RGB lighting adds visual appeal to your build, synchronizing with other compatible components. The reinforced structure prevents PCB sagging and ensures long-term durability, even with the card's substantial dimensions of 288mm length, 132mm width, and 50mm height. The 2x ATX form factor fits most modern gaming cases.

Power and Performance Specifications

Operating at 20 Gbps memory clock speed, the RX 9070 GAMING OC delivers fast data throughput for texture-heavy workloads. The card requires dual 8-pin power connectors and a recommended 750W power supply for stable operation. Whether gaming at 1440p or 4K, this graphics card provides the performance headroom needed for smooth frame rates.

Radeon RX 9070 GAMING OC 16G

FEATURES
Powered by Radeon RX 9070
Integrated with 16GB GDDR6 256bit memory interface
WINDFORCE cooling system
Hawk fan
Server-grade thermal conductive gel
RGB Lighting
Dual BIOS (Performance / Silent)
Reinforced structure

SPECIFICATION

Graphics Processing
Radeon RX 9070

Core Clock
TBD

Stream Processors
3584 ( 56CU)

Memory Clock
20 Gbps

Memory Size
16GB

Memory Type
GDDR6

Memory Bus
256 bit

Card Bus
PCI-E 5.0

Digital Max Resolution
7680 x 4320

Multi-View
4

Card Size
L=288 W=132 H=50 mm

PCB Form
ATX

DirectX
DirectX 12 API

OpenGL
OpenGL 4.6

Recommended PSU
750W

Power Connectors
8 pin x 2

Output
DisplayPort 2.1a x 3
HDMI 2.1b x 1

Accessories
VGA manual

• Chipset Manufacturer: AMD
• Chipset Series: RX
• Chipset: RX 9070
• Form Factor: 2x ATX
• Memory: 16GB
• Fans: 3
• RGB: Yes
