Intel Core i5-12400F Processor - Alder Lake Desktop CPU

The Intel Core i5-12400F delivers reliable performance for desktop computing with its 6-core, 12-thread configuration. Built on Intel's Alder Lake architecture, this processor operates at a base frequency of 2.5GHz and reaches up to 4.4GHz with Intel Turbo Boost Technology, providing responsive performance for multitasking and demanding applications.

Performance Specifications

This LGA1700 socket processor features 6 performance cores with 12 threads, offering efficient parallel processing capabilities. The 18MB cache (including 7.5MB L2 cache) ensures quick data access and smooth operation. With a processor base power of 65W and maximum turbo power of 117W, the i5-12400F balances performance with thermal efficiency.

The F-series designation indicates this processor does not include integrated graphics, requiring a dedicated graphics card for display output. This configuration is ideal for users building gaming or workstation systems with discrete GPUs.

Platform Compatibility

Compatible with LGA1700 motherboards, this processor supports up to 128GB of memory and provides 20 PCI Express lanes with both PCIe 5.0 and 4.0 support. This ensures compatibility with the latest high-speed storage devices and graphics cards, future-proofing your system build.

What's Included

This retail package includes the processor and heatsink, providing everything needed for installation in compatible LGA1700 motherboards.

Chip Name
BX8071512400F Alder Lake

Socket
LGA1700

Total Cores
6

Number of Performance Cores
6

Number of Efficient Cores
0

Total Threads
12

Max Turbo Frequency
4.40Ghz

Intel Turbo Boost Max Technology 3.0 Frequency
N/A

Performance-core Max Turbo Frequency
4.40Ghz

Efficient-core Max Turbo Frequency
N/A

Performance-core Base Frequency
2.50Ghz

Efficient-core Base Frequency
N/A

Cache
18MB

Total L2 Cache
7.5MB

Processor Base Power
65W

Maximum Turbo Power
117W

Max Memory Size (dependent on memory type)
128GB

Processor Graphics
No

Graphics Base Frequency
N/A

Graphics Max Dynamic Frequency
N/A

Graphics Output
N/A

Execution Units
N/A

Max Resolution (HDMI)
N/A

Max Resolution (DP)
N/A

DirectX Support
N/A

OpenGL Support
N/A

Intel Quick Sync Video
N/A

Intel Clear Video HD Technology
N/A

Number of Displays Supported
N/A

OpenCL Support
N/A

Direct Media Interface (DMI) Revision
N/A

PCI Express Revision
5.0 and 4.0

Max Number of PCI Express Lanes
20

Heatsink
Y

Packaging
Retail

• Socket: 1700
• On-Chip Graphics: No
• Speed: 2.5GHz
• Core Quantity: 6
• Prefix: Core i5
