AMD Ryzen 7 7800X3D Gaming Processor

The AMD Ryzen 7 7800X3D represents the pinnacle of gaming processor technology, featuring AMD's revolutionary 3D V-Cache technology for exceptional low-latency performance. Built on the advanced 5nm process with Zen 4 architecture, this 8-core, 16-thread processor delivers uncompromising performance for competitive gaming and content creation.

Performance Specifications

Operating at a base clock of 4.2GHz with boost speeds reaching 5.0GHz, the 7800X3D harnesses 104MB of total cache (512KB L1, 8MB L2, and 96MB L3) to minimize latency and maximize frame rates. The processor's 120W TDP ensures efficient power consumption while maintaining peak performance during intensive gaming sessions.

3D V-Cache Technology

AMD's 3D V-Cache technology stacks additional cache directly onto the processor die, significantly reducing memory access times and delivering measurable performance improvements in gaming workloads. This architectural advantage provides consistently high frame rates across demanding titles at any resolution.

Platform Features

The AM5 socket platform brings DDR5 memory support with speeds up to 5200 MT/s, PCIe 5.0 connectivity for next-generation storage and graphics cards, and integrated AMD Radeon Graphics with 2 cores running at 2200MHz. The processor supports up to 128GB of system memory across dual channels, with additional PCIe lanes available through compatible X670E, X670, B650E, and B650 motherboards.

Overclocking Capabilities

AMD EXPO technology enables simplified memory overclocking for enhanced performance. Precision Boost 2 automatically optimizes clock speeds based on workload demands, while Precision Boost Overdrive leverages motherboard power delivery for extended boost durations. The unlocked multiplier allows full customization through AMD Ryzen Master utility for enthusiasts seeking maximum performance.

Package Contents

This retail package includes the AMD Ryzen 7 7800X3D processor only. No heatsink or cooling fan is included, requiring a separate AM5-compatible cooling solution. The processor is backed by a 3-year manufacturer warranty.

Technical Specifications

• Socket: AM5
• Type: AMD Ryzen 7
• Clock Speed: 4.2GHz
• Turbo Speed: 5.0GHz
• #Hide#Generation: Ryzen 7th gen
• Cores: 8 Core
• Core Size: CPU Cores: TSMC 5nm FinFET
  I/O Die: TSMC 6nm FinFET
• Threads: 16
• Cache: L1 Cache: 512KB
  L2 Cache: 8MB
  L3 Cache: 96MB
• TDP: Default TDP: 120W
• Graphics: Yes
• Graphics Details: AMD Radeon Graphics
  Graphics Core Count: 2
  Graphics Frequency: 2200 MHz
  GPU Base: 400 MHz
  USB Type-C DisplayPort Alternate Mode support
• Memory: Memory Channels: 2
  Max. Memory: 128GB
  System Memory Subtype: UDIMM

  Max Memory Speed:
  1x1R - 5200 MT/s
  1x2R - 5200 MT/s
  2x1R - 3600 MT/s
  2x2R- 3600 MT/s
• Max PCI Express Lanes: 28/24 (Total/Usable)

  Additional Usable PCIe Lanes from Motherboard:
  AMD X670E: 12x Gen4
  AMD X670: 12x Gen4
  AMD B650E: 8x Gen4
  AMD B650: 8x Gen4
• Cooler: No
• Special Features: AMD 3D V-Cache technology
  AMD EXPO Technology
  AMD Ryzen Technologies
• Package Type: Retail
• Package Weight: 0.3300 kg
• Warranty: 3 Years
