AMD Ryzen 9 7900X Processor - 12-Core Desktop CPU

The AMD Ryzen 9 7900X delivers exceptional performance for demanding workloads. Built on 5nm process technology, this 7th generation processor combines 12 cores and 24 threads with boost speeds up to 5.6GHz, making it capable of handling intensive gaming, content creation, and professional applications simultaneously.

High-Performance Architecture

Featuring a base clock of 4.7GHz and turbo boost up to 5.6GHz, the Ryzen 9 7900X provides the processing power needed for complex tasks. The processor includes 76MB of total cache (768KB L1, 12MB L2, and 64MB L3) to reduce latency and improve data access speeds. With a 170W TDP (230W turbo), this CPU is designed for enthusiast-grade systems that demand maximum performance.

AM5 Platform and Memory Support

The Ryzen 9 7900X utilizes the AM5 socket, AMD's latest platform supporting DDR5 memory. The processor handles up to 128GB of system memory across dual channels, with speeds reaching 5200 MT/s for single-rank configurations. This ensures fast data throughput for memory-intensive applications like video editing, 3D rendering, and large dataset processing.

Integrated Radeon Graphics

Equipped with integrated AMD Radeon Graphics featuring 2 graphics cores at 2200 MHz, the 7900X provides display output capability without requiring a discrete graphics card. The integrated GPU supports USB Type-C DisplayPort Alternate Mode, offering flexible connectivity options for modern displays.

Connectivity and Expansion

The processor offers 28 total PCIe lanes (24 usable), providing extensive expansion capabilities for high-speed storage, graphics cards, and peripherals. Depending on your motherboard chipset (X670E, X670, B650E, or B650), you gain access to additional Gen4 PCIe lanes for maximum system flexibility.

Advanced Technologies

The Ryzen 9 7900X supports AMD EXPO Technology for simplified memory overclocking and includes AMD Ryzen Technologies for enhanced performance optimization. The TSMC 5nm FinFET CPU cores and 6nm FinFET I/O die deliver improved power efficiency while maintaining high clock speeds.

Note: This processor does not include a heatsink or fan. A compatible AM5 CPU cooler capable of handling 170W-230W TDP is required for operation.

Description

Specification

• Socket: AM5
• Type: AMD Ryzen 9
• Clock Speed: 4.7GHz
• Turbo Speed: 5.6GHz
• #Hide#Generation: Ryzen 7th gen
• Cores: 12 Core
• Core Size: "CPU Cores: TSMC 5nm FinFET
  I/O Die; TSMC 6nm FinFET"
• Threads: 24
• Cache: L1 Cache: 768KB
  L2 Cache: 12MB
  L3 Cache: 64MB
• TDP: 170W
  230W Turbo
• Graphics: Yes
• Graphics Details: AMD Radeon Graphics
  Graphics Cores: 2
  Frequency: 2200 MHz
  GPU Base: 400 MHz
  USB Type-C DisplayPort Alternate Mode support
• Memory: Memory Channels: 2
  Max. Memory: 128GB
  System Memory Subtype: UDIMM

  Max Memory Speed:
  1x1R - 5200 MT/s
  1x2R - 5200 MT/s
  2x1R - 3600 MT/s
  2x2R- 3600 MT/s
• Max PCI Express Lanes: 28/24 (Total/Usable)

  Additional Usable PCIe Lanes from Motherboard:
  AMD X670E: 12x Gen4
  AMD X670: 12x Gen4
  AMD B650E: 8x Gen4
  AMD B650: 8x Gen4
• Cooler: No
• Special Features: AMD EXPO Technology
  AMD Ryzen Technologies
• Package Type: Retail
• Package Weight: 0.1150 kg
• Warranty: 3 Years
