AMD Ryzen Threadripper Pro 9985WX Processor

The AMD Ryzen Threadripper Pro 9985WX represents the flagship of professional workstation processors, delivering exceptional multi-core performance for demanding workflows. Built on TSMC's 4nm FinFET process technology, this 64-core processor provides the computational power required for complex simulations, 3D rendering, video production, and data analysis.

Professional-Grade Performance

With 64 cores and 128 threads, the 9985WX handles heavily threaded applications with ease. The processor operates at a base frequency of 3.2GHz and boosts up to 5.4GHz, providing both sustained multi-threaded performance and responsive single-threaded workloads. The massive 320MB total cache (5120KB L1, 64MB L2, 256MB L3) ensures data remains close to processing cores, reducing latency in memory-intensive operations.

Enterprise-Class Platform Features

The sTR5 socket platform provides 8-channel DDR5 memory support with speeds up to 6400MT/s, utilizing RDIMM modules with ECC enabled by default for data integrity. With 144 usable PCIe 5.0 lanes (128 PCIe 5.0, 16 PCIe 4.0), the 9985WX supports extensive expansion capabilities for multiple high-performance GPUs, NVMe storage arrays, and professional capture cards simultaneously.

AMD PRO Technologies

Threadripper PRO 9000 WX-Series processors include AMD PRO Technologies, providing enterprise-level security features, remote management capabilities, and extended processor longevity. These features ensure business-critical systems maintain stability and security throughout their operational lifecycle.

Technical Specifications

The 9985WX operates with a 350W TDP, requiring robust cooling solutions and power delivery (cooler not included). AMD EXPO technology simplifies memory overclocking for compatible DDR5 modules. The processor ships as a retail package with a 3-year warranty, providing peace of mind for professional deployments.

Designed to Deliver. Built for Breakthroughs.

Designed for professionals and businesses that demand top-tier performance, reliability and expandability, these processors provide unparalleled multi-core performance. With this new Threadripper PRO 9000 WX-series, the ultimate workstation processor just got even faster.

Specification

• Socket: TR5
• Type: AMD Ryzen Threadripper
• Clock Speed: 3.2 GHz
• Turbo Speed: Up to 5.4 GHz
• #Hide#Generation: Ryzen 9th gen
• Cores: 64 Core
• Core Size: CPU Cores: TSMC 4nm FinFET
  I/O Die: TSMC 6nm FinFET
• Threads: 128
• Cache: L1 Cache: 5120KB
  L2 Cache: 64MB
  L3 Cache: 256MB
• TDP: Default TDP: 350W
• Graphics: No
• Memory: DDR5
  Memory Channels: 8
  System Memory Subtype: RDIMM
  System Memory Specification: Up to 6400MT/s
  ECC Support: Yes (Default Enabled)
• Max PCI Express Lanes: Total/Usable/PCIe 5.0: 148 / 144 / 128
• Cooler: No
• Special Features: AMD EXPO Technology
  AMD PRO technologies
  AMD Ryzen Technologies
• Package Type: Retail
• Package Weight: To be confirmed
• Warranty: 3 Years
