Antec P14 ARGB PWM 140mm Case Fan

The Antec P14 ARGB delivers efficient cooling performance for gaming PCs and workstations. This 140mm case fan combines hydraulic bearing technology with addressable RGB lighting for reliable thermal management and visual customization.

9-Blade Cooling Design

The 9-blade configuration generates airflow between 66.25-73.61 CFM while maintaining air pressure up to 1.60 mmH2O. This design ensures consistent heat dissipation even under increased air resistance conditions, making it suitable for radiator mounting or direct case ventilation.

PWM Speed Control

Variable speed operation from 240 to 1350 RPM allows precise fan curve tuning through your motherboard's PWM control. Adjust cooling performance based on system load, balancing between silent operation at 14.2 dB(A) and maximum airflow at 29.9 dB(A).

Hydraulic Bearing Technology

The hydraulic bearing system provides 30,000 hours of operation at 40°C or 40,000 hours at 25°C. This bearing type reduces friction and wear compared to sleeve bearings, ensuring long-term reliability with near-silent performance throughout its lifespan.

Addressable RGB Lighting

Full-spectrum ARGB illumination connects via standard 3-pin 5V headers, compatible with major motherboard RGB ecosystems. Synchronize lighting effects with your system's color scheme or create custom patterns through motherboard software.

Vibration Dampening

Eight anti-vibration rubber pads isolate the fan from case mounting points, reducing operational noise transfer. Combined with the hydraulic bearing, these pads minimize resonance and maintain quiet operation across the entire RPM range.

Dual Connector Configuration

Individual cables provide separate 4-pin PWM fan control (12V, 0.08A rated) and 3-pin ARGB lighting (5V, 0.3A). This split configuration offers flexible installation options and compatibility with systems lacking integrated RGB headers.

Technical Specifications

Dimensions: 140 x 140 x 25 mm
Bearing Type: Hydraulic
Speed Range: 240±150 to 1350±200 RPM
Airflow: 66.25-73.61 CFM maximum
Static Pressure: 1.30-1.60 mmH2O maximum
Noise Level: 14.2-29.9 dB(A)
Lifespan: 30,000 hours at 40°C / 40,000 hours at 25°C
Power Requirements: 12V DC (fan), 5V DC (LED)
Operating Voltage: 7.0-13.8V DC
Warranty: 1 Year

Package Contents

• Product Type: Case Fan
• Fan Size: 140mm
• Max Fan Speed: 1350RPM
• Fan Shroud Colour: Black
• LED Colour: Addressable RGB
• Connections: 4-Pin Fan & 3-Pin ARGB
