AX3000 Dual-Band WiFi 6 (802.11ax) PoE Access Point, support up to 5 SSIDs and VLAN, Self-defined Network, support PoE & PoE+, easy management app, AiMesh compatible

• Seamless and Extendable Connections — Enjoy uninterrupted roaming with WiFi 6 speeds of up to 3000 Mbps, support for up to 100 active devices and easy scalability to meet the evolving needs of your business network.
• Secure and Segmented Networking – Easy WiFi network settings via Self-defined Networks, and enhanced business security with VLAN support, offering up to five SSIDs for device segregation and prioritization in diverse business scenarios.
• Flexible Deployment with PoE — Support for both Power over Ethernet (PoE) connection and AC adapters, providing versatile options for installation.
• Accommodate to Any Space — Supports ceiling and wall mounting to fit into various business environments with more flexibility.
• Built for Safety and Reliability — Compliant with IEC 60601-1-2 standards, and with the top half of the device made of materials that meet the UL94 5VB plastics flammability standard*, the EBA63 ensures a stable and reliable connection.

Description

Specification

• Primary Function: Access Point
• #Hide#Access Point Mode: Yes (Access Point Mode)
• #Hide#Wireless Standard: 802.11ax (Wi-Fi 6/6E)
• Bands: Dual Band
• Wi-Fi Rating: AX3000
• Max Single Band Wi-Fi Rate: 2402 Mbps
• Max Wired Transfer Rate: 10/100/1000 Mbps
• Interface(s): 1 x 10/100/1000 Gigabit Ethernet Port (support PoE)
• Wireless Standards: IEEE 802.11a
  IEEE 802.11b
  IEEE 802.11g
  WiFi 4 (802.11n)
  WiFi 5 (802.11ac)
  WiFi 6 (802.11ax)
  IPv4
  IPv6
• Antenna(s): 4 x Internal Antennas
• Button(s): Reset Button
• Power Supply: 802.3af PoE
  12 V with max. 1.5 A current DC (power adapter included)
• Power Consumption: 9.1W
• Dimensions: 160 x 160 x 42 mm
• Weatherproof: No
• Frequency: 5 GHz: Up to 2402 Mbps
  2.4 GHz: Up to 574 Mbps
• Wireless Modes: AiMesh Node Mode
  Access Point Mode
• Wireless Functions: UTF-8 SSID
  WiFi MAC Address Filter
  Max MAC Filters : 64
  Wireless Scheduler
  OFDMA
  Beamforming: standard-based and universal
  1024-QAM high data rate
  20/40/80/160 MHz bandwidth
  Real-time Traffic Monitor
  Wired Traffic Monitor
  Wireless Traffic Monitor
• Security: "WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
  WPS
  SSH
  Self-Defined Network Type
  Max Self-Defined Network Rule: 16
  VLAN
  WiFi Scheduling: One Time Access
  WiFi Scheduling: Weekly Schedule
  WiFi share: QR code, PDF file
  AP isolate"
• Management: Web: ASUSWRT
  App: ASUS ExpertWiFi APP
• Additional Features: Wall and Ceiling Mountable
  1.7 GHz quad-core processor
  256 MB Flash
  512 MB RAM
  Time Scheduling
  Reward
  Customized Internet Schedule
• Package Contents: ExpertWiFi EBA63
  RJ-45 cable
  Power adapter
  Warranty card
  Quick start guide
  Wall-mount kit
• Package Type: Retail
• Package Weight: 0.4200 kg
• Warranty: 3 Years
