DeepCool CH260 Micro-ATX Case - Compact High-Airflow Design

The DeepCool CH260 is a compact Micro-ATX case engineered for high airflow and versatile component compatibility. This case expands on the classic DeepCool CH160 ITX design, now accommodating Micro-ATX motherboards while maintaining a small footprint of 438mm x 225mm x 312.5mm.

High-Airflow Steel Mesh Construction

Full steel mesh panels on the front and top ensure optimal airflow throughout your system. The case supports up to six 120mm fans across multiple mounting locations: two at the front, three on top (or two 140mm), and one at the rear. This extensive fan support keeps components cool even under heavy loads.

Tempered Glass Side Panel

The tempered glass side panel showcases your internal components while maintaining structural integrity. The black chassis design with ABS, SPCC, and tempered glass materials provides durability and a sleek aesthetic.

Component Compatibility

The CH260 supports Mini-ITX and Micro-ATX motherboards, including rear connector motherboards with 29.6mm backplane clearance. GPU clearance extends to 388mm with front fans installed or 413mm without. CPU cooler height limit reaches 174mm, accommodating most tower coolers. The case fits standard ATX PS2 power supplies up to 150mm in length.

Liquid Cooling Ready

Radiator support includes 120mm, 240mm, or 360mm radiators on top, plus a 120mm radiator at the rear. This flexibility allows for comprehensive liquid cooling configurations in a compact form factor.

Modern Front I/O

Front panel connectivity includes two USB 3.0 ports, one Gen2 Type-C port, and an audio/mic combo jack. Storage options include one 3.5" drive bay and one 2.5" drive bay, with four expansion slots for GPUs and other cards.

Technical Specifications

Dimensions: 438mm (L) x 225mm (W) x 312.5mm (H)
Net Weight: 5.3 kg
Materials: ABS, SPCC, Tempered Glass
Motherboard Support: Mini-ITX, Micro-ATX, Micro-ATX (Rear Connector)
Front I/O: USB 3.0 x 2, Gen2 Type-C x 1, Audio/Mic combo jack x 1
Drive Bays: 3.5" x 1, 2.5" x 1
Expansion Slots: 4 slots
Fan Support: Front: 2 x 120mm, Top: 3 x 120mm / 2 x 140mm, Rear: 1 x 120mm
Radiator Support: Top: 120mm / 240mm / 360mm, Rear: 120mm
CPU Cooler Height: 174mm
GPU Length: 388mm (with front fans) / 413mm (without front fans)
PSU Type: ATX PS2 (maximum length: 150mm)
EAN: 6933412765233
P/N: R-CH260-BKNGM0-G-1

• Form Factor: Micro Tower
• Motherboard Support: Micro ATX
• PSU Included: None
• Case Colour: Black
• LED Colour: None
• USB 3.0: 2
• Side Panel: Tempered Glass
