Gigabyte AORUS GeForce RTX 5080 MASTER 16G Graphics Card

The Gigabyte AORUS GeForce RTX 5080 MASTER 16G delivers professional-grade performance powered by NVIDIA's Blackwell architecture and DLSS 4 technology. Equipped with 16GB GDDR7 memory on a 256-bit interface, this graphics card handles demanding workloads from 4K gaming to content creation with exceptional efficiency.

Performance Specifications

Built around the GeForce RTX 5080 GPU with 10752 CUDA cores, this card operates at a boosted core clock of 2805 MHz—significantly higher than the reference 2617 MHz. The 30 Gbps memory clock ensures rapid data throughput for intensive applications. Supporting PCI-E 5.0, DirectX 12 API, and OpenGL 4.6, it delivers compatibility with current and future software requirements. Maximum digital resolution reaches 7680 x 4320 with multi-view support for up to 4 displays.

Advanced Cooling System

The WINDFORCE cooling system features Hawk fan technology designed for optimal airflow and reduced noise levels. Composite metal grease applied to the GPU and server-grade thermal conductive gel ensure efficient heat dissipation across all components. The triple-fan configuration maintains stable temperatures during extended gaming sessions or rendering tasks. Dual BIOS functionality offers Performance and Silent modes to balance power and acoustics based on your needs.

Premium Design Features

The LCD Edge View display provides real-time monitoring of card statistics, while RGB Halo lighting adds customizable aesthetics to your build. The reinforced structure with included versatile VGA holder prevents PCB sagging in your case. Measuring 360mm (L) x 150mm (W) x 75mm (H) in ATX form factor, verify case compatibility before installation. A single 16-pin power connector requires a recommended 850W PSU.

Connectivity and Warranty

Display outputs include three DisplayPort 2.1a ports and one HDMI 2.1b port, supporting the latest display technologies and high refresh rate monitors. The package includes a VGA manual, warranty notice, 12V-2x6 to 3x PCIe 8-pin adapter, AORUS identity stickers, versatile VGA holder with manual, and a screen cooling plus RGB fan. Gigabyte backs this card with a 4-year warranty when registered online.

AORUS GeForce RTX 5080 MASTER 16G

FEATURES
Powered by the NVIDIA Blackwell architecture and DLSS 4
Powered by GeForce RTX 5080
Integrated with 16GB GDDR7 256bit memory interface
WINDFORCE cooling system
Hawk fan
Composite metal grease for GPU
Server-grade Thermal conductive gel
LCD Edge View
RGB Halo
Dual BIOS (Performance / Silent)
Reinforced structure
Versatile VGA holder
4 Years Warranty (Online registration required)

SPECIFICATION

Graphics Processing
GeForce RTX 5080

Core Clock
2805 MHz (Reference: 2617 MHz)

CUDA Cores
10752

Memory Clock
30 Gbps

Memory Size
16GB

Memory Type
GDDR7

Memory Bus
256 bit

Card Bus
PCI-E 5.0

Digital Max Resolution
7680 x 4320

Multi-View
4

Card Size
L=360 W=150 H=75 mm

PCB Form
ATX

DirectX
DirectX 12 API

OpenGL
OpenGL 4.6

Recommended PSU
850W

Power Connectors
16 pin x 1

Output
DisplayPort 2.1a x 3
HDMI 2.1b x 1

Accessories
VGA manual
Warranty notice
1 x 12V-2x6 to 3x PCIe 8pin adapter
AORUS identity stickers
Versatile VGA holder
Versatile VGA holder manual
Screen cooling plus RGB fan

• Chipset Manufacturer: Nvidia
• Chipset Series: RTX
• Chipset: RTX5080
• Form Factor: 3x ATX
• Memory: 16GB
• Fans: 3
• RGB: Yes
