Intel Core i7-12700 Processor - Alder Lake Architecture

The Intel Core i7-12700 delivers high-performance computing with 12 cores and 20 threads, featuring Intel's hybrid Alder Lake architecture. This desktop processor combines 8 Performance-cores and 4 Efficient-cores to optimize workload distribution for both demanding applications and background tasks.

Performance Specifications

With a base frequency of 2.1GHz and turbo speeds reaching up to 4.9GHz, the i7-12700 handles intensive workloads including content creation, gaming, and multi-threaded applications. The Performance-cores max out at 4.8GHz while Efficient-cores reach 3.6GHz, providing flexible power management. The processor features 25MB of Intel Smart Cache (with 12MB L2 cache) for faster data access and improved responsiveness.

Power Efficiency and Thermal Design

Operating at 65W base power with a maximum turbo power of 180W, the i7-12700 balances performance with thermal efficiency. The included heatsink ensures proper cooling under standard operating conditions. This makes it suitable for builds where power consumption and heat management are priorities.

Integrated Graphics

The Intel UHD Graphics 770 provides capable integrated graphics with 32 execution units, base frequency of 300MHz, and dynamic frequency up to 1.5GHz. Supports up to 4 displays simultaneously with HDMI 2.1 (4096x2160@60Hz) and DisplayPort 1.4a (7680x4320@60Hz) output. Features DirectX 12, OpenGL 4.5, and Intel Quick Sync Video for hardware-accelerated media encoding.

Platform Compatibility

Built for LGA 1700 socket, compatible with Intel 600-series chipset motherboards. Supports up to 128GB DDR4 or DDR5 memory depending on motherboard configuration. Features PCIe 5.0 and 4.0 support with 20 lanes total, plus DMI 4.0 for high-speed chipset communication.

Technical Specifications

Chip Name
BX8071512700
Alder Lake

Socket
LGA1700

Total Cores
12

Number of Peformance Cores
8

Number of Efficient Cores
4

Total Threads
20

Max Turbo Frequency
4.90Ghz

Intel Turbo Boost Max Technology 3.0 Frequency
4.9Ghz

Performance-core Max Turbo Frequency
4.80Ghz

Efficient-core Max Turbo Frequency
3.60Ghz

Performance-core Base Frequency
2.1Ghz

Efficient-core Base Frequency
1.6Ghz

Cache
25MB

Total L2 Cache
12MB

Processor Base Power
65W

Maximum Turbo Power
180W

Max Memory Size (dependent on memory type)
128GB

Processor Graphics
Intel UHD Graphics 770

Graphics Base Frequency
300 MHz

Graphics Max Dynamic Frequency
1.50 GHz

Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1

Execution Units
32

Max Resolution (HDMI)
4096 x 2160 @ 60Hz

Max Resolution (DP)
7680 x 4320 @ 60Hz

DirectX Support
12

OpenGL Support
4.5

Intel Quick Sync Video
Yes

Intel Clear Video HD Technology
Yes

Number of Displays Supported
4

OpenCL Support
2.1

Direct Media Interface (DMI) Revision
4.0

PCI Express Revision
5.0 and 4.0

Max Number of PCI Express Lanes
20

Heatsink
Y

Packaging
Retail
Y

• Socket: 1700
• On-Chip Graphics: Yes
• Speed: 2.1GHz
• Core Quantity: 12
• Prefix: Core i7
