Strong MESHTRIAX3000UK AX3000 WiFi 6 Mesh System - 3 Pack

The Strong MESHTRIAX3000UK delivers whole-home WiFi 6 coverage across 5,000 square feet with its 3-pack mesh configuration. This AX3000 mesh system combines Easy Mesh™ technology with WiFi 6 MU-MIMO standard to provide speeds up to 3000 Mbps throughout your home.

WiFi 6 Mesh Performance

Each ATRIA Mesh AX3000 node features dual-band connectivity with 2402 Mbps on 5GHz and 574 Mbps on 2.4GHz. The system replaces your existing WiFi network without requiring changes to your modem or router. Four internal 3dBi antennas per unit ensure strong signal distribution across all coverage areas.

Expandable Mesh Network

The 3-pack configuration covers up to 300m² (5,000 sq ft), with the ability to add up to 3 additional nodes. A full 6-node setup extends coverage to 600m², making it suitable for larger homes or multi-story buildings. The system automatically organizes the network with intelligent roaming and auto-healing capabilities.

Hardware Specifications

Each node is powered by a dual-core 900MHz CPU and includes three Gigabit Ethernet ports (2x LAN, 1x WAN) with Auto MDI/MDIX support. The system supports WPA3-SAE security alongside WPA2 and WPA standards. Power, Internet, Pairing, and WiFi status LEDs provide clear system monitoring.

Advanced Mesh Features

The ATRIA Mesh app for Android and iOS enables simple network management. Built-in features include client band steering, seamless roaming, user load balancing, and auto mesh routing. The system supports multiple SSIDs (4x 2.4GHz + 4x 5GHz) and includes DHCP server, NAT/NAPT, firewall, VPN passthrough, and port forwarding capabilities.

Package Contents

Includes 3x ATRIA Mesh AX3000 units, 3x power supply units (12V/2A DC), 3x CAT5E Ethernet cables, and installation instructions. Operating temperature range: 0°C to +45°C. Each unit dimensions: 128x128x73mm, weighing 320g.

Using state-of-the-art Easy Mesh™ solution, STRONG's Wi-Fi Mesh Home Trio Pack AX3000 combines Mesh technology with the powerful Wi-Fi 6 MU-MIMO standard for ultimate speed and coverage at home. This package of 3 ATRIA Mesh AX3000 replaces your current Wi-Fi network without changing your modem or router. It brings a super-fast and seamless roaming Wi-Fi network at a speed up to 3000 Mbit/s with coverage up to 300 m². Depending on the size of your house, you can add up to 3x additional ATRIA Mesh AX3000 (up to 6x ATRIA Mesh AX3000 cover an area of up to 600 m²).

Technical specifications

WI-FI

Frequency
2412 MHz-2462 MHz & 5180 MHz-5240 MHz & 5250 MHz-5350 MHz & 5470 MHz-5580 MHz

Standards
Wi-Fi 6 - IEEE 802.11ax/ac/n/g/b/a

Signal Rate
5 GHz: Up to 2402 Mbps
2.4 GHz: Up to 574 Mbps

Security
WPATM/WPA-PSKTM & WPA2TM/ WPA2-PSKTM& WPA3-SAETM

Antenna
4* Internal Antennas (3dBi)

Transmit Power
Europe: <20 dBm (2.4 GHz),<23 dBm (5 GHz)

Supported Channels
5 GHz: 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112
2.4 GHz: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13

HARDWARE

CPU
Dual-core CPU 900MHz

Ethernet Ports
2x 10/100/1000M LAN ports(Auto MDI/MDIX)
1x 10/100/1000M WAN ports(Auto MDI/MDIX)

Buttons
Connect & Secure (WPS), Reset,ON/OFF button

LEDs
Power, Internet, Pairing, 2.4 GHz and 5 GHz Wi-Fi

Power
External power supply, 12 V/2 A DC

Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

SOFTWARE

Multiple SSID
4x2.4 GHz + 4x 5 GHz

Basic Network
DHCP client, IGMP v1/v2, IPv4/v6, WDS, WPS, WMM

Router Features
DHCP server, DNS relay/proxy, NAT/NAPT, IGMP proxy, Firewall, VPN passthrough, DMZ, URL/IP/MAC Filtering, Port Forwarding

UPnP
Universal Plug & Play Internet Gateway Device

Management
TR069/TR098/TR181, Web User Interface, Time Settings, Configuration Backup/Restore, Firmware Upgrade, System Log

ATRIA Mesh app
Android and iOS downloadable app to manage the Wi-Fi Mesh network

MESH Technology
Automatically Organized Network
Intelligent Roaming (client band steering)
Auto Configuration
Seamless Roaming
Auto MESH Routing
User Load Balancing
Auto Healing (Redundancy and Fail-over)

OTHER SPECIFICATIONS

Certification
CE

Package contents
3x ATRIA Mesh AX3000
3x Power Supply Units (12 V/2 A DC)
3x CAT5E Ethernet Cable
1x Installation Instructions, Warranty Card, Safety Instructions

System requirements
Internet Browser

ENVIRONMENT

Operating Temperature
0° C ~ +45° C

Storage temperature
-20° C~+70° C

Operating humidity
10%~90% non-condensing

Storage humidity
10%~90% non-condensing

Dimensions (WxDxH) per unit
12812873 mm

Weight per unit
320 g

• Product Type: Mesh System
• Included Nodes: 3
• Mesh Speed: AX3000
