TP-Link TL-SF1005P 5-Port Fast Ethernet PoE Switch

The TP-Link TL-SF1005P delivers reliable Power over Ethernet connectivity in a compact metal desktop design. This 5-port 10/100Mbps switch features 4 PoE-enabled ports with a 58W total power budget, making it an efficient solution for powering IP cameras, access points, and VoIP phones without additional power adapters.

4-Port PoE with 58W Power Budget

Compliant with IEEE 802.3af standard, each PoE port supports up to 15.4W power delivery. The 58W total PoE budget across ports 1-4 provides sufficient power for multiple IP cameras or wireless access points simultaneously. This plug-and-play switch requires no configuration, making deployment straightforward for surveillance systems in offices, dormitories, and small business environments.

Extended 250m PoE Transmission

The built-in extend mode button enables PoE transmission distances up to 250 meters, significantly exceeding the standard 100-meter Ethernet limitation. This extended range capability is particularly valuable for IP camera installations across large properties, parking lots, or warehouse facilities where devices need to be positioned far from the switch.

Fanless Metal Construction

The fanless design ensures silent operation while the durable metal housing provides superior heat dissipation and physical protection. At just 3.9 x 3.9 x 1.0 inches, this compact switch fits easily on desktops or can be mounted in tight spaces. The physical security lock slot adds an extra layer of protection for installations in public areas.

Network Performance

With 1 Gbps switching capacity and 0.744 Mpps packet forwarding rate, the TL-SF1005P handles Fast Ethernet traffic efficiently. Auto-negotiation and Auto MDI/MDIX on all ports eliminate the need for crossover cables. The switch supports IEEE 802.3x flow control for full-duplex mode and backpressure for half-duplex mode, ensuring smooth data transmission.

Priority and Extend Mode Controls

Front-panel buttons provide quick access to priority mode (ports 1-2) and extend mode (ports 1-4) functions. Priority mode ensures time-sensitive traffic receives bandwidth preference, while extend mode activates the 250-meter transmission capability. The store-and-forward transmission method with 2K MAC address table maintains network reliability.

Professional Fast Ethernet Switch with 4 PoE Ports
Plug and Play, with PoE Transmission for Surveillance up to 250 m

Dedicated 4-Port PoE Switch (41 W Budget) for Numerous Applications
Compliance with the 802.3af PoE standard supports up to 15.4 W on each PoE port. The total 41 W PoE power budget for the 4x PoE ports opens up a wide range of applications, such as such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

Ideal for IP Surveillance, Up to 250 m Transmissions
With extend mode, the PoE transmission distance reaches up to 250 m, perfect for IP Camera deployment in large areas.

Specifications

HARDWARE FEATURES

Interface
5x 10/100 Mbps RJ45 Ports (Ports 1–4 support 802.3af PoE)
AUTO Negotiation
AUTO MDI/MDIX

Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100O STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100O STP (maximum 100m)

Fan Quantity
Fanless

Physical Security Lock
Yes

External Power Supply
External Power Adapter (Output: 53.5 V DC / 0.81 A)

Packet Forwarding Rate
0.744 Mpps

PoE Ports (RJ45)
Standard: 802.3 af compliant
PoE Ports: Ports 1–4
Power Supply: 41 W

Mac Address Table
2K

Jumbo Frame
2 KB

Switching Capacity
1 Gbps

Dimensions ( W x D x H )
3.9 x 3.9 x 1.0 in (100 x 98 x 25 mm)

Max Power Consumption
1.9 W (220 V / 50 Hz, no PD connected)
47 W (220 V / 50 Hz, with 41 W PD connected)

Max Heat Dissipation
6.48 BTU/h(no PD connected)
160.27 BTU/h(with 41 W PD connected)

SOFTWARE FEATURES

Transmission Method
Store-And-Forward

Advanced Functions
Compatible With IEEE 802.3af/at Compliant PDs
Extend Mode Button (Ports 1–4)
Priority Mode Button (Ports 1–2)
Mac Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control For Full-Duplex Mode and Backpressure for Half-Duplex Mode

OTHERS

Certification
FCC, CE, RoHS

Package Contents
TL-SF1005LP
Power Adapter
Installation Guide

Environment
Operating Temperature: 0–40 (32–104)
Storage Temperature: -40–70 (-40–158)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing

• Ports: 5 Ports
• Managed/Unmanaged: Unmanaged
• Speed: 10/100
• PoE capable: Yes
