Ubiquiti U7-PRO-XG UniFi 7 Pro XG WiFi 7 Access Point

The Ubiquiti U7-PRO-XG represents the next generation of enterprise wireless networking with WiFi 7 technology. This ceiling-mounted access point delivers exceptional performance for high-density environments, supporting 300+ concurrent devices across 140 square meters (1,500 square feet) of coverage area.

WiFi 7 Performance with 10GbE Connectivity

Equipped with a 10 Gigabit Ethernet uplink, this access point eliminates network bottlenecks and provides the bandwidth necessary for demanding enterprise applications. The 6-stream architecture delivers maximum data rates of 5.8 Gbps on 6 GHz, 4.3 Gbps on 5 GHz, and 688 Mbps on 2.4 GHz bands. Support for EHT 320 MHz channel bandwidth on the 6 GHz band ensures future-proof wireless performance.

Multi-Band Tri-Radio Design

The U7-PRO-XG operates simultaneously across 2.4 GHz, 5 GHz, and 6 GHz frequencies with 2x2 DL/UL MU-MIMO on each band. This tri-band configuration with optimized antenna gain (6 dBi on 6 GHz, 5 dBi on 5 GHz, 4 dBi on 2.4 GHz) provides reliable connectivity across all client device types while minimizing interference in congested wireless environments.

Enterprise-Grade Features

Advanced radio management capabilities include 802.11r fast roaming, 802.11k RRM, 802.11v BSS transition management, and band steering for seamless client transitions. The access point supports wireless meshing, Passpoint (Hotspot 2.0), captive portal functionality, and Private Pre-Shared Key (PPSK) for granular network access control. RADIUS over TLS (RadSec) provides enhanced authentication security.

Flexible Installation and Power

The compact design measures 206mm in diameter by 32.5mm height and weighs 750 grams. Constructed from UV-stabilized polycarbonate and aluminum alloy with stainless steel mounting hardware, the unit includes a Lite Mount for ceiling or wall installation. PoE+ (802.3at) support with 42.5-57V DC input simplifies deployment with a maximum power consumption of 22W.

Technical Specifications

Ceiling-mounted 6-stream WiFi 7 AP with 10/5/2.5/1 GbE support.

WiFi 7 with 6 GHz support
6 spatial streams
140 m2 (1,500 ft2) coverage
300+ connected devices
Powered using PoE+
10 GbE uplink

Dimensions
d206 x 32.5 mm
(d8.1 x 1.3")

WiFi Standard
WiFi 7

Spatial Streams
6

Coverage Area
140 m2 (1,500 ft2)

Max. Client Count
300+

Uplink
10 GbE

Mounting
Ceiling, Wall
(Lite Mount Included)

Power Method
PoE+

MIMO
6 GHz
2 x 2 (DL/UL MU-MIMO)

5 GHz
2 x 2 (DL/UL MU-MIMO)

2.4 GHz
2 x 2 (DL/UL MU-MIMO)

Max. Data Rate
6 GHz
5.8 Gbps (BW320)

5 GHz
4.3 Gbps (BW240)

2.4 GHz
688 Mbps (BW40)

Antenna Gain
6 GHz
6 dBi

5 GHz
5 dBi

2.4 GHz
4 dBi

Max. TX Power
6 GHz
24 dBm

5 GHz
26 dBm

2.4 GHz
23 dBm

Max. BSSIDs
8 per Radio

Supported Data Rates
802.11be (WiFi 7)
6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320)
5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)

802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)

802.11ac (WiFi 5)
6.5 Mbps to 1.7Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)

802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Wireless Meshing
Yes

Band Steering
Yes

802.11v BSS Transition Management
Yes

802.11r Fast Roaming
Yes

802.11k Radio Resource Management (RRM)
Yes

Advanced Radio Management
Yes

Passpoint (Hotspot 2.0)
Yes

Captive Hotspot Portal
Yes

Private Pre-Shared Key (PPSK)
Yes

WiFi Speed Limiting
Yes

Client Device Isolation
Yes

WiFi Schedules
Yes

RADIUS over TLS (RadSec)
Yes

Max. Power Consumption
22W

Supported Voltage Range
42.5 - 57V DC

Networking Interface
(1) 10 GbE RJ45 port

Weight
750 g (1.7 lb)

Management
Ethernet

Enclosure Material
UV-stabilized polycarbonate, aluminum alloy

Mount Material
Stainless steel (SUS304), galvanized steel (SGCC)

LEDs
System

Channel Bandwidth
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)

Certifications
CE, FCC, IC

• Type: High Density
• Speed: 5800Mbps
• Indoor or Outdoor: Indoor
• POE Capability: 48v
• Pack Size: Single
