Ubiquiti UniFi Dream Machine Pro Max - Enterprise Network Gateway

The UDM-PRO-MAX delivers enterprise-grade network management with 10G cloud gateway capabilities, supporting 200+ UniFi devices and 2,000+ clients. This all-in-one solution combines routing, switching, security, and surveillance into a single 3U rack-mountable unit.

Enhanced Performance and Capacity

Powered by a quad-core ARM Cortex-A57 processor at 2.0 GHz with 8GB DDR4 memory, the Dream Machine Pro Max offers double the device and client capacity compared to the Dream Machine Pro/SE. The system delivers 5 Gbps routing with IDS/IPS threat detection, ensuring network security without compromising performance.

Advanced Connectivity Options

Network connectivity includes eight GbE RJ45 LAN ports and one 10G SFP+ LAN port for high-speed local connections. WAN options feature one 2.5 GbE RJ45 port and one 10G SFP+ port, providing redundant WAN with failover and load balancing capabilities. The device supports license-free SD-WAN, WireGuard, L2TP, OpenVPN, and IPsec site-to-site VPN configurations.

Integrated UniFi Protect NVR

Two 3.5" HDD bays with RAID data protection provide redundant storage for surveillance footage, while a built-in 128GB SSD handles NVR detection recordings. The integrated UniFi Protect application eliminates the need for separate NVR hardware, streamlining your surveillance infrastructure.

Comprehensive Security Features

The application-aware firewall includes signature-based IPS/IDS threat detection, content and country filtering, and VLAN/subnet-based traffic segmentation. Full stateful firewall protection works alongside WiFi QoS with UniFi APs, plus application, domain, and country-based quality of service controls.

Technical Specifications

Dimensions: 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
Weight: 4.7kg
Enclosure Material: Aluminium CNC, SGCC steel
Mount Material: SGCC steel
Processor: Quad-core ARM Cortex-A57 at 2.0 GHz
System Memory: 8 GB DDR4
Onboard Storage: 32 GB eMMC, Integrated 128 GB SSD

Networking Interface:
LAN: (8) GbE RJ45 ports, (1) 10G SFP+ port
WAN: (1) 2.5 GbE RJ45 port, (1) 10G SFP+ port

IDS/IPS Throughput: 5 Gbps*
*Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.

Power Method: (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz
(1) USP-RPS DC input, 11.5V DC, 8.7A
Power Supply: AC/DC, internal, 100W
Supported Voltage Range: 100—240V AC
Max Power Consumption: 100W

Performance:
Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting

Next Generation Security:
Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall

Advanced Networking:
License-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support

• Ports: 8
• Firewall: Yes
• Rack Mountable: Yes
