Ubiquiti UniFi Switch Ultra 8-Port PoE+ Network Switch

The USW-ULTRA-60W is a compact Layer 2 Gigabit Ethernet switch designed for professional network deployments requiring Power over Ethernet capabilities. This 8-port managed switch delivers reliable network connectivity with integrated PoE+ power distribution in a wall-mountable form factor.

Power over Ethernet Configuration

This switch provides 7 GbE PoE+ output ports capable of delivering up to 30W per port, with 52W total PoE availability when using the included 60W AC power adapter. The eighth port supports optional PoE++ input, allowing flexible power configurations. Additional power options include PoE++ input (42W available), PoE+ input (16W available), and compatibility with a 210W AC adapter (202W available) for higher-demand installations.

Network Performance Specifications

The USW-ULTRA-60W delivers 8 Gbps total non-blocking throughput with 16 Gbps switching capacity and 11.904 Mpps forwarding rate. All 8 ports support Gigabit Ethernet connectivity with auto-negotiation. Layer 2 features include port isolation, storm control, port mirroring, multicast/broadcast rate limiting, flow control, jumbo frames, and egress rate limiting.

Compact Design and Mounting Options

Measuring 203 x 76 x 33 mm and weighing just 320g, this polycarbonate-encased switch offers versatile installation options with the included wall mount bracket. The fanless design ensures silent operation suitable for office environments, retail spaces, and residential deployments.

UniFi Network Integration

Managed through the UniFi Network application (version 8.0.7 and later), this switch integrates seamlessly into existing UniFi ecosystems. Ethernet in-band management provides centralized configuration, monitoring, and troubleshooting capabilities. LED indicators display system status, PoE activity, and link/activity per port.

Operating Environment and Certifications

The switch operates across varying temperature ranges depending on power input: -30 to 60°C with PoE++ input, -20 to 45°C with 60W AC adapter, and -20 to 60°C with 210W AC adapter. Humidity tolerance spans 10-90% non-condensing conditions. CE, FCC, and IC certifications ensure compliance with international standards.

Dimensions
203 x 76 x 33 mm (8 x 3 x 1.3")

Weight
Device: 320 g (11.3 oz)
Wall mount: 45 g (1.6 oz)
60W adapter: 330 g (11.6 oz)

Enclosure Material
Polycarbonate

Management Interface
Ethernet In-Band

Networking Interface
(8) GbE RJ45 ports

PoE Interface
(7) PoE/PoE+ (Pins 1, 2+; 3, 6-)

Total Non-Blocking Throughput
8 Gbps

Switching Capacity
16 Gbps

Forwarding Rate
11.904 Mpps

Power Method
(1) 54V, 1.1A power adapter (Included)
PoE++ (Pins 1, 2+; 3, 6- and 4, 5+; 7, 8-)

Power Supply
54V, external, 1.1A/60W

Supported Voltage Range
44—57V DC

Max. Power Consumption
9W with PoE input (Excluding PoE output)
8W with AC adapter input (Excluding PoE output)

Total Available POE
PoE++ input: 42W
PoE+ input: 16W
60W PoE adapter input: 42W
60W AC adapter input: 52W
210W AC adapter input: 202W

Max. PoE+ Wattage Per Port by PSE
30W

Button
Factory Reset

Ambient Operating Temperature
PoE++ input: -30 to 60° C (-22 to 140° F)
60W AC adapter input: -20 to 45° C (-4 to 113° F)
210W AC adapter input: -20 to 60° C (-4 to 140° F)

Ambient Operating Humidity
10 to 90% noncondensing

Certifications
CE, FCC, IC

Layer 2 Features
Port isolation
Storm control
Port mirroring
Multicast / broadcast rate limiting
Flow control
Jumbo frames
Egress rate limit

System
Status

Ethernet
PoE
Link/Activity

UniFi Network
Version 8.0.7 and later

• Speed: Gigabit
• Ports: 8
• POE Capability: 48v
• Managed or Unmanaged: Managed
• Rack Mountable: No
